Manufacturer: CISSOID
Model:CHT-PLA0738C
Lead Free Status / RoHS Status:Lead free / RoHS Compliant
Stock Condition:New original, 158 pcs Stock Available.
Ship From:Hong Kong
Shipment Way:DHL/Fedex/TNT/UPS
Contact:sales@eIGBT.com
WhatsApp:+86 13410359515
| Part Number | CHT-PLA0738C |
|---|---|
| Manufacturer / Brand | Cissoid |
| Stock Quantity | 158pcs Stock |
| Description | IGBT Power Modules / Transistors & Diodes |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Condition | New Original Stock |
| Warranty | 100% Perfect Functions |
| Lead Time | 2-3days after payment. |
| Payment | PayPal / Telegraphic Transfer / Western Union |
| Shipping by | DHL / Fedex / UPS/TNT |
| Port | HongKong |
| RFQ Email | Sales@eIGBT.com |
The CHT-AMATHEA is a Medium Power
80V/3A dual-diode designed to achieve high performance in an extremely
wide temperature range: typical operation temperature goes from -55°C to
225°C.
3 product flavours are available:
●Common Anode
●Common Cathode
●Dual Series
The CHT-AMALTHEA is available in a metal can TO-257 package.
●Temperature range: -55°C to +225°C
●Maximum reverse voltage: 80V
●Max forward current @ 225°C: 3A
●Capacitance: 36pF Typ.
●Package TO-257 metal can - Isolated Case
●3 configurations available
●Rectification
●Free-wheeling
●Clamping
●General purpose
If you need support for your high temperature design, contact Cissoid.
Download CISSOID's Altium Library for IC symbols and package footprints. For installation, read the related Application Note.
Supporting its customers in the manufacturing of high temperature and high reliability hybrid modules, CISSOID delivers most of its CHT products as bare die. Please, do not hesitate to contact CISSOID to request die map information including die dimension, die finish, location and description of the bonding pads.
| Product name | Description | Ordering reference | Package | Marking |
|---|---|---|---|---|
| AMALTHEA | Dual Diode 80V/3A Common Anode | CHT-PLA0738A-TO257-T | TO-257 | CHT-PLA0738A |
| AMALTHEA | Dual Diode 80V/3A Common Cathode | CHT-PLA0738B-TO257-T | TO-257 | CHT-PLA0738B |
| AMALTHEA | Dual Diode 80V/3A Dual Series | CHT-PLA0738C-TO257-T | TO-257 | CHT-PLA0738C |
| AMALTHEA | Single Diode 80V/3A | CHT-PLA073801-D-U | Potential Good Die | - |
