ABB 5SNA 1500G450300 HiPak IGBT Module

Article source: ABB Library

1. VCE = 4500 V

2. IC = 1500 A

3. Ultra-low loss SPT++ technology

4. Very soft switching FCE diode with increased diode area

5. Exceptional ruggedness and highest current rating

6. High insulation package

7. AlSiC base-plate for high power cycling capability

8. AlN substrate for low thermal resistance

9. Recognized under UL1557, File E 196689
